INPUT VOLTAGE ........ 30-0-30 VAC RMS center
                       tapped @ nominal line
                       for amplifier. 6.6 VAC
                       RMS for filament.

I/P VOLT RANGE........ + 10% to -10%

I/P POWER @60V AC..... 122 Watts AC (Amplifiers
                       at max. deflection)

SIGNAL INPUTS ........ "X" horizontal 20V P/P
                       (+10V to -10V)
(@ MAX. DEFLECTION)    "Y" vertical 15V P/P
                       (+ 7.5V to -7.5V)
                       "Z" beam drive 4.0V
                       (max. brite)
                       1.OV black level

INPUT IMPEDANCE ...... "X".....1.3K Ohm
                       "Y".....1.3K Ohm
                       "Z"..... 270 Ohm

JUMP SPEED ........... Deflection Amp..6O usec.
                       (+10V step "X" amp)

Z BANDWIDTH .......... 10 MHz @ -3DB point

HIGH VOLTAGE ......... 14.5KV @ lb = O
                       Adjustable ± 5%
H VOLTAGE REGULATION . 2.0% max.
                       (lb O TO 100 uA)

FACTORY ADJUSTED ..... "X" & "Y' linearity
CONTROLS               H.V. adjust, Focus

CUSTOMER CONTROLS .... Contrast, brightness

ENVIRONMENTAL......... Operating ambient
                       O° to 55°C
